    High Output Plastic Extrusion Machine Single Screw Plastic Extruder 65MM Screw

    Ask Lasest Price
    Brand Name : YAOAN
    Model Number : AF-65
    Certification : CE
    Payment Terms : TT,LC
    Supply Ability : 100 SETS PER MONTH
    Delivery Time : 30-90 DAYS
    • Product Details
    • Company Profile

    High Output Plastic Extrusion Machine Single Screw Plastic Extruder 65MM Screw

    TPU, TPR, TPV Rubber Band Extrusion Machine,Plastic bands Making Machine


    Customers according to production needs, monochrome or color out of the host structure, with themold, cooling sink, traction machine, cutting machine, and air delivery systems and other components, products widely used in toys, decorations, and gift packaging purposes.


    Φ50 Three Color Rubber Band (elastic) extrusion production line configurations and quotation:


    Φ55 single screw extruder: one set

    Screw diameter: 55mm

    Screw L/D: 28:1

    Screw style: special (suitable raw material: TPR,TPU,SBS)

    The screw and the barrels are all made of high quality nitrided steel-38CrMoAIA,and are nitration austerely according to NATIONAL STANDARD, nitration hardness: screw≧740HV; harrels≧940HV. Nitration depth:0.3-0.7mm;screw:0.4-0.6mm, barrel:0.6-0.7mm;fragility is 2 grades.

    Gear box: one set

    Drive motor: 15kw (Chinese famous brand)

    Control style: frequency conversion (Delta brand)

    Assistant machine Φ30×2(set)

    Screw diameter: 30mm

    Screw L/D: 25:1

    Screw structure: special

    Gearbox (one set)

    Control power: 3kw×2

    Thermostat zones: 5 zones ( adopts Winpark temperature controller)

    Radiator zones: 3 zones

    Electrical control box: one set

    Co-extrusion mould: one set


    4m stainless steel cooling water tank: one set

    Water tank frame: one set


    1M belt Haul off machine: one set

    Haul off control power: 1.5kw

    Haul off control style: frequency inverter


    Cutting machine: one set (25 blades)

    Cutting unit control power: 3.0kw

    Cutting unit control type: frequency conversion

    Haul off roller drive motor:0.75kw

    Material collection unit: one set

    Size: 600mm*400mm*400mm
